Rear Mount PRD8400
Overview:
For those who demand a professionally groomed lawn, Woods high-performance finish mowers ensure a clean, crisp, manicured appearance year after year. Our unique rounded front, tapered-side rear discharge deck allows you to mow with better maneuverability – reducing trim time and increasing productivity. Heat-treated, a... + Read More
Features
- 84-inch cutting width, Rear Discharge
- Three-point hitch: Cat 1
- Tractor HP range: 25-40 hp
- Ideal for mowing large lawns, sports fields, and parks
- Strong, eight-gauge steel deck
- Floating lower hitch points to manage uneven terrain
- Powerful 60 hp gearbox
- Kevlar® belt with clutching cover protects parts and increases lifespan
- Anti-shimmy caster wheel springs reduce shock loads
- Tubular caster wheel arms for added strength
- ASABE quick-hitch compatibility ensures faster, easier and safer hook-ups
Specifications
| Cutting width | 84" |
| Overall width | 86" |
| Weight | 830 lbs |
| Mowing height | 1" - 4.25" |
| Deck material thickness | 8 gauge |
| Side skirt | 8 - gauge x 5.375" deep (with .536" dia. skid rod bumper) |
| Hitch/Quick-hitch compatible | Cat 1 / yes |
| Gearbox hp rating | 60 hp |
| PTO Horsepower | 25 - 40 hp |
| Blade tip speed | 17,900 fpm |
| Blade overlap | 2" |
| Blade spindle bearings | tapered rolled, greaseable |
| Blade sheave | cast-iron with taper-lock bushing |
| Blade crossbar | yes |
| Caster wheels | 4" x 10" solid, 4" x 10" pneumatic |
| Tractor PTO speed | 540 rpm |
| Driveline size | Cat 3 |
| Belt | B-section Kevlar® with clutching cover |
| Belt adjustment | spring-loaded idler |
