Specializing in farm equipment sales, parts, and service.

Rhino TR120

Double tap to zoom



Features

  • Double-Layered Deck for Optimal Durability and Easy Clean-Off
  • Smooth Obstruction Free Underside of Deck
  • Deep Deck for Larger Volume of Material
  • Cross-Braced Blade Pan Carrier

Specifications

Model TR120
Cutting Width 120''
Overall Width 127''
Overall Length 116'' - Lift
156'' - Pull
116'' - Offset
Cutting Height 1''-12''
Height Adjustment Ratchet Jack - Lift
Hydraulic Cylinder - Pull
Jack Stand Std - Pull
Hitch CAT 2 & 3 QH
Semi-Mount, Pull
Amount of Offset - Semi-Mt Hitch 15'' R or L
Blade Carrier Pan
Blades 1/2'' x 4'' Updraft
Blade OverLap 4''
HP Required (Min.) 80 - Lift
55 - Pull/Semi
Gearbox Rating - Center 210 HP
Gearbox Rating - Outboard 205 HP
Gearbox Oil (85W-140) Factory Filled
Output Shaft Diameter 2 3/8''
Blade Tip Speed - 540 RPM 16,063 FPM
Blade Tip Speed - 1000 RPM 16,167 FPM
Axle Protection - Pull Type Spring Shock Absorber
Cutting Capacity (Max) 3''
Driveline Size CAT 4
Driveline Protection Slip Clutch
Deck Thickness 10 Ga (Upper & Lower)
Side Skirt 1/4'' x 10''
Tires & Wheels
Safety Tow Chain Std - Pull
