Specializing in farm equipment sales, parts, and service.

Rhino TW168

Double tap to zoom



Features

  • Slip clutch
  • Torque dampeners
  • CAT IV drive-line
  • 10 gauge deck
  • 1/4" side skirts
  • Quick hitch compatible

Specifications

Model TW168
Cutting Width 168''
Overall Width 176''
Overall Length 112'' Lift
155'' Pull
Cutting Height 1''- 14''
Height Adjustment Ratchet Jack - Lift
Cylinder - Pull
Jack Stand Standard - Pull
Hitch Lift CAT 2 QH & 3 QH, or Pull
Blade Carrier Bar
Blades 1/2'' x 4'' Flat (Others Optional)
Blade OverLap 4''
HP Required (Min.) 80 Lift
50 Pull
Gearbox Rating - Center 125 (540) / 140 (1000)
Gearbox Rating - Outboard 125 (540) / 140 (1000)
Gearbox Oil (85W-140) Factory Filled
Output Shaft Diameter 2 3/8''
Blade Tip Speed - 540 RPM 13,300 FPM
Blade Tip Speed - 1000 RPM 13,200 FPM
Axle Protection Spring Shock Absorber - Pull
Cutting Capacity (Max) 2''
Driveline Size CAT 4
Driveline Protection Slip Clutch
Deck Thickness 10 Ga
Side Skirt 1/4'' x 11''
Tires & Wheels Foam Filled 21'' x 7'' 12''
Safety Tow Chain Std - Pull
Light Kit Std
Weight (Approx) 3258 Lbs
