Delivers maximum durability and corrosion resistance, with a stability enhancing low center of gravity design.
Locking Caster Wheels
Enables the operator to lock the caster wheels for increased stability on varied terrain.
Starts and stops the pump and foam marker simultaneously (when installed), enabling precise application while freeing the operator’s hands.
Springs both forward and back, reducing the chances of the boom catching and being damaged.
Enables easy access to the engine for service, or for cleaning the hopper.
Only one annual grease point, so you can go all season without required maintenance.
ZS3624 - NA in California
|Front Tires||13 x 6.5-6|
|Rear Tires||18 x 7.5-8|
|Onboard Intelligence||Digital Speedometer|
|Drive System||Pump & Wheel Motor|
|Fuel Capacity||5-gallon (18.9-L) fuel tank|
|Ground Speed||0-7.0 mph (11.3 kmph) forward, 0-4.0 mph (6.4 kmph) reverse|
|Hopper Capacity||120 lbs. + two 50 lbs. fertilizer trays; hydraulic motor|
|Spread Width||Adjustable from 3 ft. up to 25 ft|
|Tank Capacity||24 gal (Two 12 gal.)|
|Spray Rate||Capacity per Nozzle - 0.22 gpm at 30 psi, 0.25 gpm at 40 psi|
|Spray Width||2 ft, 4 ft, 6 ft, or 8 ft|
Accessories and Attachments
Foam Marker (Jr/Mid Replaces Fert Box)
The foam marker system visually assists the operator with providing accurate product coverage. The foam marker comes complete with frame, fittings and hoses and may be used on all twin cylinder Z-Sprays.
20-Gallon Auxiliary Tank
Add 20 gallons of capacity to your Junior 36 giving you a total of 44 gallons. Allows you to use three separate products or use all three tanks at the same time. This kit comes with quick connects for easy removal of the spreader allowing you to switch back and forth between tank and spreader.
7 Gallon Auxiliary Tank (Left Side, Replaces Fert Box)
The 7-gallon auxiliary tank allows for use of multiple liquid products. Includes frame, hoses, and fittings.
Hose Reel Kit, JR36 (Replaces Fert Box)
HOSE REEL KIT, JR36 (FERT BOX REPLACE)
Z-Spray Parts Kit
Services Z-Spray Junior 36 models serial 408,644,346 and higher.
7-Gallon Isolated Tank (Right Side)
The 7-gallon isolated tank allows the user to spot treat utilizing different chemicals than those being used in the primary tanks. Includes a 5.0 GPM pump, frame, and 15’ coil hose. When using an Isolated tank, we recommend installing an alternator kit which is sold separately.
