Specializing in farm equipment sales, parts, and service.

Woods CP30

Double tap to zoom



Features

  • 30-inch cutting width
  • Cutting depth range: 0-6 inches
  • Manual controls attach to any skid steer
  • Top pivot design to self-level drum and chassis for higher down force and smoother cuts
  • Optional water kit for increased longevity
  • Optional step drum and stripe removal drum for added versatility

Specifications

Hydraulic flow classification high-flow
Working width 30" (762.0 mm)
Depth of cut 0-6" (0-152.4 mm)
Number of teeth 74
Side shift (right) 0-22" (0-558.8 mm)
Tilt +/- 15°
Hydraulic flow requirement 30 - 32 gpm (114 - 121 lpm)
Hydraulic pressure requirement 2,500 - 3,500 psi (172-241 bar)
Operating weight 2,450 lbs (1,114 kg)
Depth control mechanism hydraulic
Tilt control mechanism hydraulic
Side shift mechanism hydraulic
Hydraulic function activation means manual or electric
