Woods TL84A

Double tap to zoom



Features

  • 84-inch cutting width
  • Direct drive hydraulic motors – no maintenance or adjustments necessary
  • Dual-drive motors power both ends – eliminating rotor twist
  • Recessed drive motors for easy maneuvering in tight spaces
  • Offset mounting covers right side loader tracks when operating in reverse
  • Bi-directional tine rotation for tilling in both forward and reverse

Specifications

Overall width 97" (2,387.6 mm)
Working width 84" (2,133.6 mm)
Working depth 6" (152.4 mm)
Overall height 31" (787.4 mm)
Number of tines 40
Tine rotation forward or reverse
Operating weight 825 lbs (375 kg)
Driveline (2) in - line hydraulic motors
Tine speed 74 - 247 rpm
Hydraulic flow requirement 24 - 60 gpm (91-227 lpm)
Hydraulic pressure requirement 3,000 - 4,000 psi (207-276 bar)
