Woods BB840X

Double tap to zoom



Features

  • 84-inch Single-Spindle Cutter
  • Three-point hitch: Cat 1 and 2
  • Tractor HP range: 40-120 hp
  • Cutting capacity up to 3-inches
  • Standard adjustable baffles for superior material distribution
  • Optional dual tail wheels
  • Exclusive quick-change pins enable speedy blade changes in the field

Specifications

Cutting width 84"
Transport width 91.5"
Overall length 128"
Cutting height 2" - 12"
Approximate weight 1416 lbs
PTO Horsepower 40 - 120 hp
Tractor PTO speed 540 rpm
Hitch Cat 1 & 2 / Clevis
Quick hitch compatible yes
Driveline Cat 4
Driveline protection slip clutch
Gearbox output shaft diameter 2"
Gearbox horespower 120 hp
Blades (2) .5" x 4"
Blade composition heat-treated alloy steel
Cutting capacity 3"
Blade carrier round stump jumper
Blade mount system quick-change blade pins
Blade tip speed 16,000 fpm
Blade pin diameter 1.5"
Frame & deck support 3" x 4" full length structural beams
Skid-shoes Heavy-duty replaceable
Rear bumper 2" tubular
Cutter deck thickness 10 gauge
Deck side depth 12.6"
Side frame thickness .25"
Tail wheel 4" x 16", laminated
Tail wheel mount 4-point
Belting / Banding chain shielding optional
