Woods BB60X

Double tap to zoom



Features

  • 60-inch Single-Spindle Cutter
  • Three-point hitch: Cat 1
  • Tractor HP range: 25-50 hp
  • Cutting capacity up to 1.5-inches
  • Exclusive quick-change pins enable speedy blade changes in the field

Specifications

Cutting width 60"
Transport width 65.5"
Overall length 104"
Deck length 70"
Cutting height 1" to 9"
Approximate weight 604 lbs
PTO Horsepower 25 - 50 hp
Tractor PTO speed 540 rpm
Hitch Cat 1/Clevis
Quick hitch compatible yes
Safety Shielded Driveline Cat 3
Driveline protection shear pin or slip clutch
Gearbox output shaft diameter 1.57"
Gearbox horsepower 65 hp
Blades (thickness x width) (2) .38" x 3"
Blade composition heat-treated alloy steel
Blade carrier oval stump jumper
Blade mount system/pin diameter quick-change blade pins/1.5 inch
Number of spindles 1
Blade speed 914 rpm
Blade tip speed 14,355 fpm
Blade rotation CCW
Deck side depth 9.4"
Tail wheel - laminated tire 4" X 16"
Frame & deck support 3" x 4" full-length structural beams
