Woods BB48X

Double tap to zoom



Features

  • 48-inch Single-Spindle Cutter
  • Three-point hitch: Cat 1
  • Tractor HP range: 15-50 hp
  • Cutting capacity up to 1.5-inches
  • Exclusive quick-change pins enable speedy blade changes in the field

Specifications

Cutting width 48"
Transport width 53.5"
Overall length 92"
Deck length 58"
Cutting height 1" - 9"
Approximate weight 498 lbs
PTO Horsepower 15 - 50 hp
Tractor PTO speed 540 rpm
Hitch Cat 1 / Clevis
Quick hitch compatible yes
Safety Shielded Driveline Cat 3
Driveline protection shear pin or slip clutch
Gearbox output shaft diameter 1.57"
Gearbox horsepower 65 hp
Blades (thickness x width) (2) .38" x 3"
Blade composition heat-treated alloy steel
Blade carrier oval stump jumper
Blade mount system/pin diameter quick-change pins
Number of spindles 1
Blade speed 914 rpm
Blade tip speed 13,000 fpm
Blade rotation CCW
Deck side depth 9.4"
Tail wheel - laminated tire 4" X 16"
Frame & deck support formed channel
Rear bumper 2" tubular
Cutting capacity 1.5"
