The hard-working T5 is the best utility tractor with deluxe features and big power to handle every chore.
TERRAGLIDE™ FRONT AXLE SUSPENSION: OUTSTANDING TRACTION. UNSURPASSED COMFORT.
The optional New Holland Terraglide™ suspended 4WD axle protects the tractor, mounted implements and the operator from heavy shock loads.
TRANSMISSIONS PERFECT FOR THE WORK YOU DO.
New Holland offers a selection of easy-to-operate transmissions that allow you to match your tasks and operating preferences.
INCREASED PRODUCTIVITY AND EFFICIENCY.
T5 engines reduce your fuel bills and reduce emissions using the very latest technology from FPT Industrial. Four models are Tier 4B compliant and the largest two models meet Stage 5 emissions standards.
CLEAN PERFORMANCE. RESPONSIVE PRODUCTIVITY.
T5 Series tractors deliver the power you need for loading, making hay and much more. They boast the latest in engine technology thanks to in-house engine development specialist: FPT Industrial. Their award-winning Hi-eSCR solutions has been extensively tested and have clinched numerous awards.
MODELS T5.130 AND T5.140
The two most powerful T5 tractors are powered by an FPT Industrial NEF four-cylinder, 4.5-liter engine that produces maximum horsepower ranging from 130-140 hp. The NEF 4.5 liter engine has an ideal power curve, delivering peak power at 1800 rpm, which is perfectly aligned with the most frequently used engine speeds for both PTO and road work.
ECOBLUE™ HI-ESCR 2 EXPLAINED
The T5.130 and T5.140 comply with Stage 5 emissions standards, which mandate a further 40% reduction of Particulate Matter content compared to previous Tier 4B / Stage 4 regulation. This is achieved thanks to the new HI-eSCR 2 technology developed by FPT Industrial. This innovative after-treatment system is a maintenance-free, patented solution that minimizes operating costs. The NEF 4.5 liter engine features a compact and simple layout that is EGR-free and has been neatly packaged under the hood, resulting in improved visibility, extreme productivity and reliability
MODELS T5.90, T5.100, T5.110 AND T5.120
These T5 Series tractors feature 3.4-L, 4-cylinder, 16-valve engines with common-rail fuel injection to maximize power and efficiency. These super-quiet engines develop between 107 and 117 horsepower and up to 362 lbs/feet of torque for guaranteed productivity. Add in a power-to-weight ratio of 85.7 lbs/hp and you have a perfect farming partner. Low emissions are achieved with the ECOBlue™ Compact HI-eSCR System (Selective Catalytic Reduction) with light CEGR (Cooled Exhaust Recirculation). This solution requires no diesel particulate filter (DPF) and no need for regeneration or operator input or the inconvenience of stopping. It all adds up to outstanding efficiency, which is what you’ve come to expect of the Clean Energy Leader.
THE IMPORTANCE OF TRANSIENT RESPONSE
Transient response is your productivity guarantee. Put simply, since your T5 engine breathes only clean fresh air, it can react more quickly when placed under load. So when you’re transporting fully loaded trailers or grain carts and you encounter a hill, you’ll be able to maintain constant forward speed with quicker engine rpm recovery.
SIMPLE ENGINE SPEED MANAGEMENT
A versatile mid size tractor needs to be equally suited to PTO and heavy draft applications. With Engine Speed Management (ESM), the advanced engine management system precisely fuels the engine so it accommodates fluctuations in engine load while maintaining the desired engine speed. For convenience, two engine speeds can be memorized. You can then simply toggle between the speeds using a button on the transmission controller. In applications where a constant PTO speed is required, just select Engine Speed Management to ensure the speed is maintained even under changing loads. In many applications, this allows you to maintain a fixed forward speed in difficult terrain.
THE PERFECT SPEED
New Holland offers a choice of transmissions to match your applications and your preferences:
• Auto Command™ CVT (T5.130 and T5.140)
• Dynamic Command™ 24x24 8-step semi-powershift (T5.130 and T5.140)
• Electro Command™ 16x16 semi-powershift (T5.110 and T5.120)
• Dual Command™ Hi-Lo transmission (T5.90, T5.100, T5.110 and T5.120)
AUTO COMMAND™ CONTINUOUSLY VARIABLE TRANSMISSION (CVT)
(Available on T5.130 and T5.140 models only)
You control the multi-award winning Auto Command CVT using the intuitive CommandGrip™ handle. It allows you to change speed and direction and responds based on force-based movement. You can set three target speeds and easily change between them. You can also choose from four driving modes to match your driving style:
• Auto Mode. Once the desired target speed is achieved, Auto Command™ will match the engine and transmission to maintain it.
• Cruise Mode. Cruise Mode allows the operator to achieve a set target speed at the touch of a button, and to maintain the speed for economy and productivity.
• Manual Mode. Allows the operator to manually set the required engine and forward speed, independently of each other.
• PTO Mode. As soon as the PTO is engaged, Auto Command will operate to achieve a constant engine speed.
DYNAMIC COMMAND™ T8-STEP SEMI-POWERSHIFT TRANSMISSION
(Available on T5.130 and T5.140 models only)
The 24x24 Dynamic Command™ transmission enables you to shift between eight gears under load, without changing ranges. These carefully designed speeds within each range correspond directly with common field work or transporting ground speeds — eliminating operator range shifts mid-task for greater productivity.
• New Holland Ground Speed Management II (GSM II) manages both engine and transmission speeds to optimize performance and economy. It is simple to set up, using CVT-like functionality to dependably analyze data relating to the setting you choose, engine load and forward speed.
• The Dynamic StartStop feature allows for clutch-free loader work. When working at lower operating speeds, simply depress the brake when coming to a stop, and when you release the brake pedal, the tractor will automatically shuttle and start to move again.
16X16 ELECTRO COMMAND™ SEMI-POWERSHIFT
(Available on T5.110 and T5.120 models only)
The Electro Command™ transmission gives you eight thumb-button powershifts without making a shift lever range change. You can see the selected gear at a glance thanks to the large gear display. Top transport speeds of 25 MPH (40kph) are achieved at a mere 2040 rpm (with 18.4-34 rear tires). The result? Your T5 will slash your fuel bills while reducing in-cab noise.
AUTOSHIFT MODES FOR COMFORT AND PRODUCTIVITY
Add the AutoShift™ option with the Electro Command transmission and gear shifting is taken care of for you automatically. With Auto Transport, the tractor shifts seamlessly through eight speeds like a vehicle with an automatic transmission. Auto Field mode manages both the engine speed and transmission to optimize performance and economy. In power-take-off (PTO) applications, where a constant engine speed is the priority, the system will select the transmission ratio to match the load on the engine. In draft applications, engine speed is allowed to drop to fully exploit the available torque rise before selecting a lower ratio under load.
ERGONOMIC POWER SHUTTLE WITH 3 AGGRESSIVENESS SETTINGS
You can operate the convenient, column-mounted electro hydraulic power shuttle without taking your hand off the wheel for increased safety during loader work. You can even regulate the shuttle aggressiveness setting with an ergonomically positioned switch. Select soft for general field work, standard for daily tasks and the aggressive position for near instantaneous direction changes during loader work. You can even change the setting while on the move.
OPTIONAL ISOBUS CLASS 2 OR 3
ISOBUS allows you to control all of your implements—balers, mowers and more—using your T5 IntelliView™ IV tractor monitor (optional parts supplied). The T5.130 and T5.140 offer the two-way communication of ISOBUS 3, allowqing the implement to control the speed of tractor to achieve maximum productivity.
24X24 DUAL COMMAND™ TRANSMISSION
(Available on T5.90, T5.100, T5.110 and T5.120 models only)
This easy-to-use transmission makes a big difference in your day. It gives you a Hi-Lo speed in each of the four gears within the three ranges. Simply use the push buttons on the side of the control lever. In addition, the Dual Command transmission offers a PowerClutch button that allows you to shift between gears within a range without clutching with your foot, as well as a smooth, left-hand electrohydraulic shuttle lever that conveniently returns to the central rest position for quick direction changes. Select from three shuttle aggressiveness settings using a rocker switch.
