New Holland RF450 SuperFeed

Double tap to zoom



Features

MAKE QUALITY SILAGE BALES ON A BUDGET

The RF450 SuperFeed™ round baler handles extra-tough baling conditions and produces dense 4’x5’ bales, including silage bales with up to 80% moisture. This tough baler is an ideal choice for small livestock farms and contract operators looking for an alternative to more premium variable-chamber silage balers.

Rugged bale chamber

The RF 450 SuperFeed uses seven rolls and 29-bar chain and slat system. Thanks to its rugged build and tough floor roller bearings, these balers have the size and strength to cope with dense and heavy bales.

Built for hard work, wet or dry

An RF450 SuperFeed baler is designed to handle demanding conditions, including sticky silage crops, short dry material, brittle straw, or long-stalked crops like cornstalks or sudan grass.

Larger swaths? No problem

With its wide, standard,2.25-meter pickup and powered rotor feeder, RF450 SuperFeed balers are able to tackle larger swaths at higher speed. The RF450 SuperFeed™ has 27 tines per bar, for a total of 108 pickup tines for a clean sweep in all working conditions.

Non-stop productivity

A radial pin slip clutch protects the pickup drive. If a blockage occurs, the clutch opens to protect the drive, but automatically resets as additional material is drawn into the bale chamber. For added protection, a shear bolt is also fitted, and the PTO intake shaft on all models has slip clutch protection.

Powered rotor feeder

The standard 2.25-meter pickup with rotor feeder actively feeds material into the RF450 SuperFeed bale chamber. To ensure smooth feeding, the rotor tines are mounted in a spiral pattern. The rotor drive is shearbolt-protected for your peace of mind.

Easy to check. Easy to care for

Vertically hinged side panels provide easy access to the rugged, simple and efficient driveline. To ease maintenance, standard equipment includes seven main drive chains with automatic lubrication plus a bank of grease points to ensure all key bearings are easy to lubricate.

Specifications

RF450 SuperFeed™
Bale size
Bale diameter in. (cm) 59 (155)
Bale width in. (cm) 47 (120)
Pickup
Width (DIN) in. (m) 88.6 (2.25)
Number of tines / tine bars 108 / 4
Windguard Tine rake / Plate
Number of pickup tines per row 23
Protection Radial pin slipclutch
540-rpm PTO Standard
Suspension Standard
Pickup wheels Pneumatic
Feeding
Type in. (mm) 18.5 (470) rotor feeder
Number of augers 2
Bale formation
Type strokes/min 48
Density system in. (mm) 28 (710)
Number of rollers 7 rolls & 29 bars
Wrapping
Wrap material: twine / net / twine & net Standard/Optional at exrtra cost /Optional at exrtra cost
Twine ball capacity 4
Control Auto-Wrap™ bale monitor
Spare roll capacity 1 active, 1 stored
Baler dimensions
Length, includes bale ejector in. (mm) 148 (3760)
Height in. (mm) 96.5 (2450)
Adjustable Track width Min. / Max. in. (cm) 74.4 / 80.7 (189 / 205)
Weight * lbs (kg) 2,700 (1,225)
Tires 18L-16.1SL 10 PR
PTO
Minimum PTO power (hp) 85
Front access ladder Optional at extra cost
Bale kicker
Bale kicker Optional at extra cost
Automatic lubrication
Automatic lubrication Optional at extra cost
