Seedbed Preparation TC5111

Double tap to zoom



Features

Hybrid Machine with Heavy-Duty Toggle-Trip Shanks

When equipped with heavy-duty toggle-trip shanks, this “hybrid” unit works in the 8" to 12" range (rather than the 13" to 15" range required by disk rippers) while horizontally fracturing soil much better than a disk chisel. Toggle-trip shanks can’t float. They either run at the set depth or trip – there is no in between. The Heavy-Duty Toggle Trip Shank has a 2,450-pound horizontal trip force and will automatically reset when tripped.

Exclusive 22" Turbo Blades

On 7½" spacing, the 22" Turbo Blades outperform competitive tools by sizing and mixing residue on the surface. While competitive, concave-disc tools simply cut off and roll long, stringy stalks, Turbo Blades size residue to ensure maximized mixing and enhanced decay.

Available Shank Combinations

Order the Turbo-Chisel the way you want it with two different shank combinations: Standard Chisel (pictured: two shanks on the left) or Heavy-Duty Parabolic (pictured: shank on the far right).

Walking Tandem Axles

Maintain consistent mainframe height for accurate, consistent tillage depth control.

Optional Patented Angled Rear Chopper Wheel Attachment

Patented angled chopper wheels pull dirt back into shank voids, leveling soil while maintaining the vertically-tilled profile left by the shanks.

Exclusive Maintenance-Free Bearings

Reduce maintenance time and extend life of bearings. These 360° self-aligning bearings are never sideloaded. A six-lip seal on each side locks in grease and prevents contamination. Additionally, the walking beam pivots utilize Teflon™-coated bushings, eliminating the need for tapered bearings and grease in pivot points.

Specifications

Model TC5111
SHANK SPACING 15"
COULTER SPACING 7.5"
TRANSPORT TIRES 12.5Lx15
12-ply (4)
WEIGHT (approx lbs) 9,835
PTO H.P. REQ (min) Option 20: 20hp per shank
Option 26: 30hp per shank
DIMENSIONS
TILLAGE WIDTH 13' 9"
TRANSPORT WIDTH 14' 3"
TRANSPORT HEIGHT N/A
TILLAGE INFO
CENTER SECTION 10'
1ST WING SECTION 2' 6"
