Bush Hog XD65C Backhoe

Double tap to zoom



Features

Performance Features
  • Digging Depth (2 ft. flat bottom): 6’4”
  • Overall Operating Height (fully raised): 91”
  • Reach from Swing Post: 100”
  • Bucket Rotation: 180°
  • Swing Arc: 150°



Safety Features

  • Stabilizer Width: 72”

Specifications

Model XD65C
Transport Height (with boom fully retracted) 64.5"
Transport Width (with stabilizers up) 41"
Loading Height (bucket at 60° rotation) 62"
Ground Clearance 8 1/2"
Transport Length 56"
Transport Weight (base unit only - no bucket or mounts) 500 lbs.
Digging Depth (2 ft. flat bottom) 6'4"
Overall Operating Height (fully raised) 91"
Reach from Swing Post 100"
Bucket Rotation 180°
Swing Arc 150°
Stabilizer Width (Spread) 72"
Stabilizer Width (Transport) 41"
Operating Pressure 1800 psi
SAE* Dipper Boom Digging Force 1250 lbs.
SAE* Bucket Digging Force 2054 lbs.
Boom Lift Capacity (end of dipper 3' from ground) 250 lbs.
Hydraulic Volume Requirements 3½-6 gpm*
Flow Divider -
Recommended Tractor HP 18-28 HP
Recommended Skidsteer Requirements Mini Skidsteer
Bucket Sizes Available 9, 12, 15, 18
3 Point Hitch n/a
Cylinder Diameters
Main Boom Cylinder Diameter 2.5
Dipper Cylinder Diameter 2.25
Bucket Cylinder Diameter 2.5 (x1)
Swing Cylinder Diameter 2
Stabilizer Cylinder Diameter 2
Extender Cylinder Diameter -
