APT portable compressors APT 440-100 JD T4F EB
Overview:
With strong undercarriages and heavy-gauge bodies, APT portable compressors
are robust and durable. Just pull one to the worksite and get busy.
Features
- Extremely reliable Kubota diesel engines
- Ultra-efficient oil-injected air end
- All air outlets at the rear of the machine for ease of use
- Easy to service with great access to filters, engine and air receivers
- Trailer-mounted with road lights as standard
- Options include cold weather kits, aftercoolers, fine air filters, and more on select models
Specifications
| Model | APT 185 T4F |
| Free Air Delivery - CFM | 400-440 |
| Working Pressure - psi (Bar | 150-100 |
| Pressure Range - psi (Bar) | 58-125 (4-8.6) |
| Discharge Outlets | 1 @ 1- 1 ⁄2" & 2 @ 3/4" |
| Oil Capacity - gal. (L) | 5.4 (20.5) |
| Engine Make | John Deere |
| Model | 4045HFC04 |
| Displacement - L | 4.5 |
| Cylinders | 4 |
| EPA Tier | Tier 4 Final |
| HP | 115 |
| Rated Speed (High) - rpm | 2,400 |
| Rated Speed (Low) - rpm | 1,500 |
| Fuel Tank Capacity - gal. (L) | 52 (197) |
| Fuel Consumption @ 100% Load - gal./hr (L/hr) | 6.5 (24.5) |
| Fuel Autonomy @ 100% Load - Hours | 9 |
| Sound Pressure Level @ 23' (7m) @ 75% Load - dB(A) | 76 |
| Trailer Dimensions (L x W x H) - in. | 161 x 71.5 x 70 |
| Weight (Wet) - lbs. (kg) | 4,555 (2066) |
| Support Mounted (L x W x H) - in | 113 x 71.5 x 65 |
| Weight (Wet) - lbs. (kg) | 4,590 (2082) |
