Features
Standard Equipment
- 500 gallon 304 stainless steel tank
- 36 GPM / 600 PSI Comet® diaphragm pump
- 36" diameter, 8-blade axial flow steel fan
- 2-speed gearbox with neutral
- Heavy duty PTO shaft
- Tank drive shaft with rundown clutch
- 1" 304 stainless steel mechanical agitation
- Cable type remote control
- 304 stainless steel strainers
- Teejet© ceramic nozzles
- Galvanized fan housing
- Composite nylon adjustable air vanes with specialty valves
- 13.5Lx16.1 ANS field and turf tires
- Heavy duty adjustable hubs and spindles
- DK hitch
Options
- 1,000 gallon machinery upgrade
- 600 gallon 304 stainless steel tank
- 2-point turning hitch
- Tower extensions (built to specification)
- 100 GPM / 145 PSI Myers© 2-stage centrifugal pump
- 53 GPM / 600 PSI Comet© pump (Model IDS 2200)
- Myers 2 stage centrifugal pump
- Hydraulic and electric spray control valves
- 2" and 3" stainless steel fill connections
- Tank drain plumbed with valve
- Indented tank (60" wide)
- Multiple tire configurations
- 2-Port nozzle body
- 3-Port nozzle body
- No Drip rear manifold diaphragm
- 4 valve multi-zone tree sensor
- Lights
- Fan tuning to match your tractor PTO HP
- Burm blower attachment
- Vineyard Up-sprays
Specs
Specifications Short Stack
- Length 500 Gal. = 15' / 600 Gal. = 15' 6"
- Width 500 Gal. = 6’ 6" / 600 Gal. = 6' 9"
- Height Tower top = 109" / 62" to 68" (adjustable)
- Weight 500 Gal. = 2,910 pounds / 600 Gal. = 2,960 pounds
- Air Velocity 130 mph (approximate)
- PTO Horse Power Requirements: 80 – 100
Specifications Volute
- Length 500 Gal. = 15' / 600 Gal. = 15' 6"
- Width 500 Gal. = 6’ 6" / 600 Gal. = 6' 9"
- Height Tower top = 77" / 62" to 68" (adjustable)
- Weight 500 Gal. = 2,910 pounds / 600 Gal. = 2,960 pounds
- Air Velocity 130 mph (approximate)
- PTO Horse Power Requirements: 80 – 100
